Our Machinery

CNC MILLING MACHINE –HASS VF3

  • Model : VF3
  • Brand : HASS
  • Control : FANUC 0I-MF
  • Accuracy : 0.001- 0.07 microns
  • Table Travel Size : 500 X 550 X1000 mm
  • RPM : 8100 RPM
  • Loading Capacity : 800Kg
  • Qty : 1Nos

CNC TURNING CENTRE- JYOTI

  • Model : DX 2007B
  • Brand : JYOTI
  • Control : FANUC 0I-MF
  • Accuracy : 0.010 microns
  • Std Turing Dia : 250 mm
  • Max Turing Dia :  365 to 410 mm
  • Turing length max : 700 mm
  • RPM : 4000 RPM
  • Spindle Bore : 75mm
  • Loading Capacity : 100 to 150kg
  • Qty : 2Nos

CONVENTIONAL MILLING MACHINE

  • Model : No.4
  • Brand : S&T
  • DRO Control : Sino
  • Accuracy : 0.02mm
  • Table Travel Size : 250X1256X500mm
  • Loading Capacity : 250Kg
  • Qty : 1Nos

CNC TURNING CENTRE- ACE JOBBER XL

  • Model : JOBBER XL
  • Brand : ACE
  • DRO Control : FANUC 0I-MATE TD
  • Accuracy : mm
  • Table Travel Size : 270X500X400mm
  • RPM : 4000 RPM
  • Loading Capacity : 800Kg
  • Qty : 1Nos

COSMOS VERTICAL MACHINING CENTRE- CVM 1160

  • Model : CVM 1160
  • Brand : COSMOS
  • DRO Control : FANUC 0I-MF
  • Accuracy : 0.01 micron
  • Table Travel Size : 1250x550x600mm
  • RPM : 8000 RPM
  • Loading Capacity : 800Kg
  • Qty :  1Nos

Tool Developemnt Facilities – Design and Tool Manufacturing

Design Facility

  •  Design team consist of 2 members with team leaders and 1 designer.
  •  Software:  Uni-Graphics  AutoCAD to perform design & development of products and molds.
  •  The team has hands on experience in designing of products and molds and precision components for Engineering Industries..

Tool room

 From Précising to Try out done in house…

 HASS Vertical Machining, ACE turning center, Lokesh turning center

With Tool room machineries Like…….

  • Electronica – CNC EDM
  • Super drilling Machine
  • Cylindrical grinding Machine , Surface Grinding Machines,  Milling Machine
  • Lathe
